Descriptions:

1)  Design standard: ASME B16.34

2)  Threaded ends: ANSI B1.20.1,BS 21/2779,DIN 259/2999,ISO 228

3)  Testing: API 598,EN12266

4)  Mateiral:ASTM A351-CF8M,CF8,CF3M,SS316,SS304

                      ASTM A216-WCB

5)  Size: 1/4”, 3/8”, 1/2”, 3/4”, 1”, 1-1/4”, 1-1/2”, 2”, 2-1/2",3" ,4"

6)  Working pressure: 1000PSI,PN63

7)  Seat Material: PTFE,RPTFE,PPL

8)  Working temperature: -20 to 180°C

9)  Working medium: Water, Oil, Gas, Acid, etc

Features:

1)  Blow-out proof stem

2)  Investment Casting Body and Caps

3)  Pressure Blance Hole in Ball Slot

4)  Full Bore,Reduce Bore is available,"L" Bore and "T" Bore is available

5)  Threaded type: NPT,BSPP,BSPT,DIN is available

Pressure Testing:
