Descriptions:

1) Design standard: ASME B16.34, API608

2) Threads ends: ANSI B1.20.1,BS 21/2779,DIN 259/2999,ISO 228

3) Testing: API 598

4) Material:ASTM A351-CF8M,CF8,CF3M,SS316,SS304

                     ASTM A216-WCB

5) Size: 1/4”, 3/8”, 1/2”, 3/4”, 1”, 1-1/4”, 1-1/2”, 2”,2-1/2” ,3” ,4”

6) Working pressure: 1000 PSI,PN63

7) Seat Material: PTFE,RPTFE,PPL

8) Working temperature: -20 to 180°C(PTFE)  ,-20 to 300°C(PPL)

9) Working medium: Water, Oil, Gas, Steam, Acid, etc

Features:

1) Blow-out proof stem

2) Investment Casting Body

3) Pressure Blance Hole in Ball Slot

4) ISO5211 Direct Mounting Pad

5) Full Bore

6) Threaded type: NPT,PT,BSP,BSPT,DIN is available

7) Locking device is available
